4.5.5 DISPLAY

The waveform display is affected by settings of the oscilloscope. A waveform can be measured once it is
captured. The different styles to display a waveform on the screen give significant information about it.
There are two modes to display waveforms; Single-window and Double window.
Refer to Horizontal Controls for more information.
Press the Utility button and then the DISPLAY button on page 4 of the Utility menu.
Options
Type (F1)
Persistency (F2)
DSO mode (F3)
Contrast (F4)
Grid (F2)
Grid Intensity (F3)
Refresh Rate (F4)
Wave Bright (F2)
BL Keep (F3)
Menu Keep (F4)
Settings
Vectors
Dots
Auto
0.2S-8S selectable
Infinite
YT
XY
0-15
Dotted Line
Real Line
Off
Auto
30, 40, 50 Frames
Unlimited
5, 10, 30, 60 Sec
Unlimited
5, 10, 30, 60 Sec
www.burntec.com
Comments
'Vectors' fills up the space between adjacent sample points
in the display; 'Dots' displays the sample points only.
Length of time to display each displayed sample point.
YT – normal or standard signal view
XY – XY format
Use the Multifunction control to set the display contrast.
Menu page 2
Set up for display of the grid lines.
Use the Multifunction control to set the brightness of the
displays Grid lines.
Set refresh rate of display (default is Auto)
Menu Page 3
Use multifunction control arrow keys to change waveform
brightness.
Set how long the Backlight is on before it turns off
Set how long the Menu is displayed before it turns off
55 MS6000-EU-EN-V1.3 7/12
