Utility Mode menu continued ...
(menu page 1 of Pass/Fail)
Enable Test - Open / Close (On / Off)
Pass/Fail (F3)
Source - CH1 or Ch2
(menu page 3)
Start
End
(menu page 2 of Pass/Fail)
Msg display (F2) - Open/Close – turn On/Off Message display
Pass/Fail
Out (F3) – Pass, Fail, Pass Ring, Fail Ring - Alarm settings
Out Stop (F4) – Pass , Fail - Stop test on pass or fail
Page (F5) – Change to page 3 of Pass/Fail menu
(menu page 3 of Pass/Fail)
Regular (F2) - Alter vertical or horizontal divisions of the test Mask
Pass/Fail
Create (F3) - Adjust Vertical and Horizontal div and press Create to set Mask
Save (F4) – Save Mask division settings to SD or USB memory
Back (F5) – Go back to main Utility menu
Type Off, Record, Play, Save
Record (F4)
Rec, Source, Time Interval, End Frame
(menu page 3)
Start / End on page 2
Type
Filter (F2) Source
(menu page 4) Up
Down
Display (F3) This menu item controls the Display. See section 5.5.5 for these settings
(menu page 4)
Acquire (F4) This menu item controls the signal Acquire mode. See section 5.5.6 for these
(menu page 4) settings.
DMM (F2) On – Turn on the Digital multimeter functions.
(menu page 5) Off – Turn off the Digital multimeter functions.
Frequency (F3) On –
(menu page 5) OFF -
Fan Test –
More (F4)
SD Status –
(menu page 5)
System Features – Store Depth, SD Card, Video, Net Card
*Self Calibration: The self calibration routine can optimize the precision of the oscilloscope to
accommodate the ambient temperature. To maximize the accuracy, perform the self calibration when
the ambient temperature changes by 5
Tip: Press any menu button on the front panel to remove the status display and to enter a
corresponding menu.
Off, Low Pass, High Pass, Band Pass, Band Stop.
o
C or more. Follow the instructions on the screen.
