Acquisition
Acquisition Modes
Acquisition Rate,
typical
Single Sequence
Inputs
Input Coupling
Input Impedance,
DC coupled
Probe Attenuation
Supported Probe
Attenuation
Maximum Input
Voltage
Normal, Peak Detect, and Average
Up to 2000 waveforms per second per channel (Normal acquisition
mode, no measurement)
Acquisition Mode
Normal, Peak Detect
Average
DC, AC or GND
1MΩ ±2% in parallel with 20pF ±3pF
1X, 10X
1X, 10X, 100X, 1000X
Overvoltage Category
CAT I and CAT II
CAT III
Installation Category II: derate at 20dB/decade above 100kHz to 13V
peak AC at 3MHz* and above. For non-sinusoidal waveforms, peak
value must be less than 450V. Excursion above 300V should be of less
than 100ms duration. RMS signal level including all DC components
removed through AC coupling must be limited to 300V. If these values
are exceeded, damage to the oscilloscope may occur.
www.burntec.com
Acquisition Stop Time
Upon single acquisition on all
channels simultaneously
After N acquisitions on all
channels simultaneously, N can
be set to 4, 8, 16, 32, 64 or 128
Maximum Voltage
300V
RMS
Category
150V
RMS
80
(10×), Installation
(1×)
