4. MATH MENU: Display the waveform math operations. See the table below for details.
The MATH menu contains source options for all math operations. Press the M/R button.
Operations
Enable (F1)
Operate (F2)
FFT (F2)
Note: All selected menus are highlighted orange.
Source Options
ON
OFF
CH1+CH2
CH1-CH2
CH2-CH1
CH1xCH2
CH1/CH2
CH2/CH1
Source(F3)
CH1 or CH2
www.burntec.com
Comments
ON enables the Math functions
Add Channel 1 to Channel 2.
Subtract the Channel 2 waveform from the Channel
1 waveform.
Subtract the Channel 1 waveform from the Channel
2 waveform.
Multiply CH1 with CH2
Divide CH1 by CH2
Divide CH2 by CH1
WINDOW (F4) – There are 5 types of window
settings available: Hanning, Flattop, Rectangular,
Bartlett, and Blackman
Zoom (F2 page 2): Use the FFT Zoom button to
adjust the window size.
Scale: x1, x2, x5, x10.
Vertical Base (F3 page 2): dBrms or Vrms
