Measurements
Cursors
Automatic
Measurements
General Specifications
Display
Display Type
Display Resolution
Display Contrast
Probe Compensator Output
Output Voltage,
typical
Frequency, typical
Internal Memory
2G SD Card
Power Supply
Supply Voltage
Power Consumption
Fuses
Battery
Voltage difference between cursors: V
Time difference between cursors: T
Reciprocal of T in Hertz (1/ΔT)
Frequency, Period, Mean, Peak-to-peak, CycleRMS, Minimum,
Maximum, Rise Time, Fall Time, Positive Width, Negative Width,
Delay 1-2↑, Delay 1-2↓, +Duty, -Duty, Base, Top, Middle, Amplitude,
Overshoot, Preshoot, RMS, Off
5.6 Inch width LED Backlight Display
240 (Vertical) X 320 (Horizontal) pixels
Adjustable (16 steps) with a progress bar
About 2Vpp into ≥1MΩ load
1kHz
Accommodates up to 32G card (accessible through battery
compartment)
100-120VAC (±10%), 45Hz to 440Hz
RMS
120-240VAC (±10%), 45Hz to 66Hz
RMS
<30W, (approx. 3 hours)
Two (2) fast-acting internal fuses: 1A (600V) and 12A (600V)
7.4V li-ion rechargeable
www.burntec.com
81 MS6000-EU-EN-V1.3 7/12
