Slope Trigger
Slope Trigger Mode
Slope Trigger Point
Time Range
Overtime Trigger
Alter (Swap)
Trigger
CH1
CH2
Trigger when < (Less than), > (Greater than), = (Equal), or ≠ (Not
Equal); Positive slope or Negative slope
Equal: The oscilloscope triggers when the waveform slope is equal to
the set slope.
Not Equal: The oscilloscope triggers when the waveform slope is not
equal to the set slope.
Less than: The oscilloscope triggers when the waveform slope is less
than the set slope.
Greater than: The oscilloscope triggers when the waveform slope is
greater than the set slope.
Selectable from 20ns to 10s
The leading edge: Rising edge or Falling edge; Time Setting: 20-10s
Internal Trigger: Edge, Pulse Width, Video, Slope
Internal Trigger: Edge, Pulse Width, Video, Slope
www.burntec.com
79
MS6000-EU-EN-V1.3
