Menu and Option Buttons

As shown below, these four buttons on the front panel are used mainly to recall relative setup menus.
SAVE/RECALL: Displays the Save/Recall menu for setups and waveforms. (Save/Recall)
MEASURE: Displays the Measure menu. (MEAS)
CURSOR: Displays the Cursor menu. (CUSOR )
UTIILITY: Displays the Utility menu. (UTILITY)
DISPLAY: Displays the Display menu. Click Utility button and go to menu page 4, Display is F3.
ACQUIRE: Displays the Acquire menu. Click Utility button and go to menu page 4, Acquire is F4.
4.5.1

SAVE/RECALL

Press the SAVE/RECALL button to save or recall oscilloscope setups or waveforms.
The first page shows the following menu.
Options Settings
Wave
CH1
Source (F1)
CH2
Media (F2) USB
Flash
Location (F3)
Save (F4)
Page (F5)
Recall (F2)
(menu page 2)
Delete (f3)
(menu page 2)
F1 Press F1 to engage Waveform mode
Select a waveform display to store.
SD
Select the location for saving the data
Used with SD and Flash only. Select the memory location
Save the current set up
Change page from 1 to 2
Recall a specified setup based on the memory and location.
Delete a specified setup based on the memory and location.
