Invert (F2)
(menu page 2)
Reset (F3)
(menu page 2)
Ground Coupling
Ground Coupling is used to display a zero-volt waveform. Internally, the channel input is connected with
a zero-volt reference level.
Remove Waveform Display
To remove a waveform from the screen, first push the menu button to display the vertical menu, and then
push the appropriate Channel button to remove the waveform. A channel waveform which is
unnecessary to display can be used as a trigger source or for math operations.
3.
VOLTS
Control the oscilloscope to magnify or attenuate the source signal of the channel waveform. The vertical
size of the display on the screen will change (increase or decrease). The key F3 may be used to switch
between Coarse and Fine. In the Fine resolution setting, the vertical scale readout displays the actual
VOLTS setting. The vertical scale changes only when the control is set to Course and the VOLTS control
is adjusted.
Off
Inverts the waveform relative to the reference level.
On
Resets Vertical settings to default
27
www.burntec.com
MS6000-EU-EN-V1.3
7/12
