4.5.4

UTILITY

Push the UTILITY button to display the Utility Menu as follows.
Options
Display the software and hardware versions, serial number and other information
Sys Info (F1)
about the oscilloscope.
(menu page 1)
Insert a USB disk with an upgrade program; the disk icon at the top left corner is
Update (F2)
highlighted. Press F4 to Confirm the Update Program button; the Software Upgrade
(menu page 1)
dialog will pop up. Press F2 (Highlighted Update) to cancel operation.
Press this option and the Self Calibration dialog will pop up. Press F4 to Confirm and
Self Cal* (F3)
perform the self calibration. Press F3 (Highlighted Self Cal) to cancel. Remove all
(menu page 1)
probes before test.
Set System parameters. Sound (On/Off), Language (English, Chinese), Interface
System (F2)
color, Time Set (Date and Time), PC Set (USB or NET).
(menu page 2)
Set the meters Auto-Off timing when Action is set to PowerOff. Set Auto-Off time (F2)
Shutdown (F3)
using the Multifunction control arrow keys. Press F3 to confirm setting changes,
(menu page 2)
Press F4 to cancel changes, Press F5 to go back to main Utility menu.
Record a video of your waveforms.
Play
USB to SD
Video (F4)
SD to USB
(menu page 2)
Delete
Back – go back to the main Utility menu
Probe Check
Probe
Probe Ck (F2)
Check
(menu page 3)
Finish
Cancel
- (CH-1x, CH2-1x, CH1-10x, CH2-10x) Set to match probe setting.
- Turn on 1KHz Comp signal
- Turn off Comp signal
- Cancel Probe Check
51
