Overtime Trigger: In Pulse Width trigger mode, it may take some time for a trigger to occur. Since a
complete pulse width is not needed to trigger the oscilloscope, it may be desired to trigger just upon the
overtime point. This is called Overtime Trigger. Press on TRIG to enter Trigger mode.
Options
Type
Source (F2)
Polarity (F3)
Mode (F4)
Page (F5)
Overtime (F2)
(menu page 2)
Coupling (F3)
(menu page 2)
Noise Reject
50% (F4)
Page (F5)
Settings
O.T.
CH1
Select channel to source the trigger
CH2
Positive
Select to trigger on positive or negative pulses.
Negative
Normal
Select the type of trigger. The Normal mode is best for most
Auto
applications.
Single
Change page from 1 to 2
Adjust timing using the Multifunction control.
AC
DC
Selects the components of the trigger signal applied to the
HF Reject
trigger circuitry.
LF Reject
Change page from 2 to 1
