Delta Time Measurement
Accuracy
(Full Bandwidth)
Position Range
Vertical
A/D Converter
VOLTS Range
Position Range
Analog Bandwidth in
Normal and Average
modes at BNC or with probe, DC
Coupled
Selectable Analog Bandwidth Limit,
typical
Low Frequency Response (-3db)
Rise Time at BNC, typical
Single-shot, Normal mode
± (1 sample interval +100ppm × reading + 0.6ns)
>16 averages
± (1 sample interval + 100ppm × reading + 0.4ns)
Sample interval = s/div ÷ 200
MS6060
MS6100
4ns/div to 8ns/div
20ns/div to 80μs/div
200μs/div to 40s/div
MS6200
2ns/div to 10ns/div
8-bit resolution,
each channel is sampled simultaneously
2mV/div to 5V/div at input BNC
2mV/div to 200mV/div, ±2V
>200mV/div to 5V/div, ±50V
2mV/div to 20mV/div, ±400mV
50mV/div to 200mV/div, ±2V
500mV/div to 2V/div, ±40V
5V/div, ±50V
20MHz
≤10Hz at BNC
MS6060
<5.8ns
75
www.burntec.com
(-8div × s/div) to 20ms
(-8div × s/div) to 40ms
(-8div × s/div) to 400s
(-4div × s/div) to 20ms
MS6100 MS6200
3.5ns <1.8ns
