Extech Instruments MS6100 User Manual page 43

Type
Polarity (F2)
When (F3)
Set PW (F4) Pulse Width
Page (F5)
Coupling (F2)
Noise Reject
Back (F3)
Type
Polarity (F2)
Overtime (F3)
Coupling (F4)
Noise Reject
Back (F5)
Pulse
Positive
Select to trigger on positive or negative pulses.
Negative
=
≠
< Select the trigger condition.
>
Use Multifunction control to set Pulse width.
Set Menu page to 1 or 2
AC
DC
Select the components of the trigger signal applied to the trigger
HF Reject
circuitry.
LF Reject
Displays initial Alter mode Trigger screen to allow CH selection
O.T.
Positive
Select to trigger on positive or negative pulses.
Negative
Use Multifunction control to set Overtime timing.
AC
DC
HF Reject
Selects the components of the trigger signal applied to the
LF Reject
trigger circuitry.
Displays initial Alter mode Trigger screen to allow CH selection
www.burntec.com
43 MS6000-EU-EN-V1.3 7/12
