4.5.2

MEASURE

Push the MEAS key to view the following menu.
There are 23 types of measurements and up to 8 can be displayed at a time.
Options Settings
Modify (F5)
Source (F1)
Type (F2) Frequency
Average/Mean
Maximum
Delay 1-2 ↑
Delay 1-2 ↓
Comments
Press F5 to Select the measure Source and Type.
CH1
Select the measure source.
CH2
Calculate the waveform frequency by measuring the first cycle.
Period Calculate the time of the first cycle.
Calculate the arithmetic mean voltage over the entire record.
Calculate the absolute difference between the greatest and the
Pk-Pk
smallest peaks of the entire waveform.
Calculate the actual RMS voltage measurement of the first
CRMS
complete cycle of the waveform.
Examine the waveform record of all points in the current window
Minimum
and display the minimum value.
Examine the waveform record of all points in the current window
and display the maximum value.
Measure the time between 10% and 90% of the first rising edge
Rising
of the waveform.
Measure the time between 90% and 10% of the first falling edge
Falling
of the waveform.
Measure the time between the first rising edge and the next
+ Width
falling edge at the waveform 50% level.
Measure the time between the first falling edge and the next
- Width
rising edge at the waveform 50% level.
The delay of the rising time between Channel 1 and Channel 2
The delay of the falling time between Channel 1 and Channel 2
Positive duty cycle =(Positive pulse width)/Period x 100%.
+ Duty
Measured from the first waveform.
Negative duty cycle =(Negative pulse width)/Period x 100%.
- Duty
Measured from the first waveform.
Voltage of the statistical minimum level, measured over the entire
Base
waveform
Voltage of the statistical maximum level, measured over the
Top
entire waveform
