Table 28: Simrad 3000 Digital Output Format - Applanix POS MV V5 Installation And Operation Manual

Table of Contents

Advertisement

Item
Header LSB
Header MSB
Roll LSB
Roll MSB
Pitch LSB
Pitch MSB
Heave LSB
Heave MSB
Heading LSB
Heading MSB
Note: POS MV sends records using the Simrad 3000 format at an update rate from one to 200 Hz; TOV is updated
at the same rate. The recommended minimum baud rate for use with this format is 19200 baud at 100 Hz.
TSM 5265 Format
You can use this format with the Thompson TSM 5265 multibeam sonar. The output message
supplies the sonar with a time tag (roll, pitch and heave), heading and sonar velocity. POS MV
updates the message and the TOV from one to 200 times per second.
The message is a 24-byte data string with the following format.
Header: 90 hex
Time tag: double precision float, UTC time in seconds of the week
Roll format: 2's complement, LSB = 0.01°, roll sense is user selectable from the MV-
POSView Controller program
Pitch format: 2's complement, LSB = 0.01°, pitch sense is user selectable from the
MV-POSView Controller program
Heave format: 2's complement, LSB = 1 cm, heave sense is user selectable from the
MV-POSView Controller program
Heading format: LSB = 0.01°, 0 to 359.99°, positive = clockwise
Longitudinal velocity format: 2's complement, LSB = 0.1 cm/s, positive = forward
Transverse velocity format: 2's complement, LSB = 0.1 cm/s, positive = starboard
Down velocity format: 2's complement, LSB = 0.1 cm/s, positive = down
The recommended minimum baud rate for use with this format is 38400 baud at 100 Hz.
You can use the MV-POSView Controller program to change the sense of the roll, pitch and
heave outputs. You can also select the TSS or the Tait-Bryan convention of rotations for the
Copyright © Applanix Corporation, 2017
POS MV V5 Installation and Operation Guide

Table 28: Simrad 3000 Digital Output Format

Byte
0
0x00
1
0x90
2
±180°
3
4
±180°
5
6
±327 m
7
8
0 to 359.99°
9
Value
Units (If Applicable)
N/A
0.01°
0.01°
1 cm
0.01°
Interfaces
and Data Formats
3-19
