2.0 Installation

Installation of the Position and Orientation system for Marine Vessels (POS MV) is reasonably simple,
provided the installation instructions in this manual are carefully followed. Installation and connection of
the POS Computer System (PCS), the Inertial Measurement Unit (IMU) and the Global Navigation
Satellite System (GNSS) antennas should only take a few hours.
This section of the POS MV V5 manual explains each stage of the installation. By following these
instructions, you can unpack, install and configure the system so that it is ready to operate with minimal
delay.

Handling Precautions

To prevent damage to the system components handle all POS MV assemblies with care. The following
paragraphs explain the special handling precautions that apply to the IMU, PCS and GNSS antennas.
Inertial Measurement Unit
The IMU contains sensitive and expensive solid-state
accelerometer and gyro components. Permanent damage to
these components will result if handled roughly.
Exercise care when handling this unit; in particular, be careful when placing the IMU on or mounting it to
any surface. Field repair of the IMU is not possible. If this unit develops a fault or becomes damaged it
must be returned to Applanix for repair. Refer to Technical Support and Service on page A-1 for
procedures.
POS Computer System
Field repair of the PCS is not recommended. If this unit develops a fault or becomes damaged it must be
returned to Applanix for repair. Refer to Technical Support and Service on page A-1 for procedures.
Consider the following when handling the PCS:
• Handle with care.
• Do not drop from any height
• Observe standard Electrostatic Discharge (ESD) procedures.
• Refer to Circular Connectors for a guide on handling the connectors.
GNSS Antennas
Applanix supplies the POS MV with two identical GNSS antennas - handle these with care. Avoid
scratching or damaging the antenna housings in any way.
