POS MV V5 Installation and Operation Guide
Specifications
Humidity
IMU (OceanMaster)
IMU (WaveMaster &
WaveMaster RM):
PCS (POS MV V5):
PCS (POS MV V5-1):
PCS (POS MV V5-2):
GNSS Antenna:
Ingress Protection
PCS-76/80/84/86/92
IMU-42/64/69
IMU-45/65/70
Shock & Vibration (IMU)
OceanMaster
WaveMaster & WaveMaster RM
7-6
10 - 80% RH
0 - 100% RH
10 - 80% RH, non-condensing
10 - 95% RH, nom-condensing
10 - 95% RH, non-condensing
0 - 100% RH
to be deployed in a between decks
environment, protected from weather
to be deployed in a between decks
environment, protected from weather
suitable for deployment in weather or pole
mounted below the water surface
Operating:
90 g, 6 ms terminal saw tooth
Non-Operating: 220 g, 5 ms half-sine
Operating:
35 g, 6 ms terminal saw tooth
Non-Operating: 40 g, 5 ms half-sine
