6. Replace cable if not repairable.
Replace
1. Connect GNSS antenna power and data cable at both GNSS and PCS (Figure 113 on page E-
15). Do not over tighten. Protect free ends of cable from damage or contamination.
2. Apply waterproof sealing tape or silicone sealant to protect TNC antenna connector.
3. Replace power cable to PCS rear panel (starting page 9-20).
4. Observe PCS front panel power-on procedures (starting on page 4-1).
POS Computer System
There are no user replaceable parts inside. Service shall be
performed by trained and qualified personnel. If you suspect a
fault condition with the PCS contact Applanix Customer
Support, refer to page A-1 for instructions.
To remove or replace the PCS complete this procedure.
Tools
• Cross tipped screwdrivers
• Straight tipped screwdriver
• Set of SAE or metric open-end or combination wrenches appropriate to remove or secure the
PCS to its mounting location
Remove
1. Observe PCS front panel power-off procedures (starting on page 4-27).
2. Remove power cable from PCS rear panel (starting page 9-20).
3. Remove PCS from mounting location.
4. Tag and remove PCS rear panel connectors.
Replace
1. Same location:
a) Install PCS rear panel connectors.
b) Install PCS in mounting location.
c) Replace power cable to PCS rear panel (starting page 9-20).
