POS MV V5 Installation and Operation Guide
Tools
and Diagnostics

Regular Maintenance

Important:
1. Equipment shall be serviced only by qualified personnel.
2. The PCS (POS MV V5, POS MV V5-1 and POS MV V5-2) shall be grounded via the safety ground
screw or stud.
3. Power to the POS system should be protected by a user-supplied, resettable circuit breaker.
POS MV has a minimal requirement for scheduled maintenance on its subassemblies and components.
Performing these procedures at the recommended intervals enables the POS MV to maintain the highest
standard of service and performance throughout its lifetime.
Inertial Measurement Unit
The
IMU
accelerometer and gyro components. Permanent damage to
these components will result if handled roughly.
Unauthorised opening of the IMU housing will void the warranty. The
IMU is a sealed unit that contains no user serviceable parts and does
not require internal maintenance.
8-6

Figure 58: Base 1/2 Diagnostics Window, Details Tab

contains
sensitive
and
expensive
solid-state
I
MPORTANT
