POS MV V5 Installation and Operation Guide
Interfaces
and Data Formats
NMEA sentence types
Binary data formats
Base 1 and 2 GNSS outputs
Base 1 and 2 GNSS inputs
Auxiliary 1 and 2 GNSS inputs
GNSS 1 and 2 COM port access
Table 12 identifies the default COM port settings.
Note: Baud rates may require different settings, other than the default settings, for the transmission of various
sentence formats.
NMEA Data Formats
The PCS can be configured to use any number of the five COM ports to output data using the National
Marine Electronics Association (NMEA) 0183 format at rates up to 50 Hz. POS MV makes twelve
sentence formats available.
1. $xxGGA: global system position fix data
2. $xxGGK: time, position, position type and DOP values
3. $xxHDT: heading - true data
4. $xxVTG: course over ground and ground speed data
5. $xxGST: GNSS pseudorange noise statistics
6. $xxRMC:
7. a) $PASHR: attitude data
b) $PASHR-TSS: attitude data (TSS indicates the use of the TSS standard instead of the Tait-
Bryan standard, see page 2-29 for a description)
3-2

Table 12: Default COM Port Settings

Baud Rate
Parity
Data Bits
Stop Bits
Flow Control
Output Select
Input Select
9600
None
8 Bits
1 Bit
None
None
None
