Table 4 identifies the configuration for the COM ports.
POS Computer System - POS MV V5-1 & POS MV V5-2
The PCS is the heart of the POS MV V5 systems. The PCS footprints are shown in Appendix E .
Install the PCS
Remove the PCS from its transit case to allow connection and operation. The MV V5-1 and MV V5-2 PCS
is a sealed unit and may be installed in almost any location that is convenient.
Observe the following installation constraints:
• Observe the environmental limitations starting on page 7-5.
• The PCS is sealed so the only way for it to shed heat is via conduction, either to the air or another
metal surface. Allow for air circulation around the PCS or remove the rubber feet and bolt the
PCS to another metal surface that can conduct the heat away. If necessary, provide additional
fan ventilation to prevent overheating.
• Do not mount the PCS to a vibrating surface or one that may experience severe shocks.
• A minimum of 15 cm (~6 in) clearance is required behind the PCS for cable connection.
• Provide sufficient cable lengths to allow easy connection to the connectors on the PCS rear panel
or cable stubs supplied with the PCS.
Rear Panel Electrical Connections
The rear panel of the PCS provides connections for power and communications with sensors and other
devices, see Figure 8.
The POS MV V5-1 PCS footprint is shown in Appendix E . There are ten connectors located on the rear
panel of the PCS, see Figure 8. Each rear panel connector supports a single cable except for the I/O and
Copyright © Applanix Corporation, 2017
POS MV V5 Installation and Operation Guide

Table 4: COM Port Configuration

Setting
Baud Rate 2400 to 115200
Parity None, Even, Odd
Data Bits 7, 8
Stop Bits 1, 2
Flow Control Hardware, Software, None
Value
Installation
2-13
