descriptions on pages 2-24 and 4-8 respectively, for instructions on how to measure and enter these
installation parameters.

Power-Off

The initial power-off sequence for the POS MV system occurs in three stages:
a) Save parameter and configuration changes
b) Exit the MV-POSView Controller program and power-off the controlling PC
c) Power-off the POS MV system
Save Changes
Powering-off the PCS before the MV-POSView displays the
confirmation message panel may corrupt the settings held in
NVM.
Whenever changes are made to the POS MV installation parameters or its configuration, they must be
saved to NVM in order to retain them for the next power-on sequence.
The MV-POSView Controller program displays a message panel to confirm that it has saved the settings
successfully to NVM. Wait for this message to appear prior to powering-off the PCS or the POS MV
system.
Save Parameter Values
Select Settings, Save Settings from the MV-POSView menu bar to save all parameter settings to NVM.
Refer to the Save Settings description on page 4-29 for more information.
Perform the following to check that the PCS has stored the parameters correctly:
1. Select File, Exit (or press Alt, F4) to close the MV-POSView Controller program.
2. Press and hold the POWER switch on the PCS front panel until the POWER light starts flashing.
3. Wait thirty seconds and then press and hold the POWER switch to power-on the PCS and
illuminate the POWER light.
4. Start the MV-POSView Controller program.
5. Select Settings, GAMS Calibration Control and check that the PCS has saved all the GAMS
installation parameters correctly. Select the Cancel button.
Save Configuration
Select File, Save POS Config from the MV-POSView menu bar to save the new configuration settings to
the PC. Refer to the Manage Multiple Configurations description on page 4-30 for more information.
