POS MV V5 Installation and Operation Guide
Specifications
Physical Characteristics
Size and Weight
OceanMaster
IMU type 26
IMU type 36
IMU type 38
IMU type 40
IMU type 44
IMU type 52
IMU type 64
IMU type 65
WaveMaster & WaveMaster RM
IMU type 26
IMU type 37
IMU type 39
SurfMaster & SurfMaster RM
IMU type 69
Housing type 0
Housing type 101
IMU type 70
Elite
IMU type 21
IMU type 33
IMU type 57
PCS (POS MV V5):
PCS (POS MV V5-1):
PCS (POS MV V5-2)
Zephyr GNSS Antenna: 165 mm
382AP GNSS Antenna: 146 mm
540AP GNSS Antenna 178 mm
7-4
Size
203 mm X 203 mm X 116 mm
158 mm X 158 mm X 124 mm
208 mm X 196 mm
131 mm X 163 mm X 124 mm
126 mm X 179 mm X 127 mm
119mm x 149mm x 110mm
158mm x 158mm x 124mm
132mm x 176mm x 158mm
203 mm X 203 mm X 116 mm
158 mm X 158 mm X 124 mm
208 mm X 196 mm
43mm x 47mm x 13mm
158 mm X 158 mm X 124 mm
132mm X 114 mm
200 mm X 197 mm X 176 mm
229 mm X 315 mm X 196 mm
126 mm X 179 mm X 127 mm
483 mm X 44 mm X 334 mm
167 mm X 185 mm X 68 mm
160 mm X 164 mm X 66 mm
X 76 mm
X 63 mm
X 73 mm
Weight
2.1 kg
2.5 kg
5.5 kg Al, 8.4 kg Ti,
13 kg SS
1.8 kg
2.6 kg
1.8 kg
2.4 kg
2.5 kg
2.1 kg
2.5 kg
5.5 kg Al, 8.4 kg Ti,
13 kg SS
0.02 kg
2.5 kg
2.4 Kg
4.8 kg
1
3.5 kg
2.6 kg
3.9 kg
2.5 kg
2.5 Kg
0.64 kg
0.5 kg
0.45 kg
