Set up the Control Head

Use the following instructions to power on the control head and confirm the
360 Imaging transducer and the GPS Receiver/Heading Sensor are detected by the unit.
CAUTION! It is important to finish all installation connections before powering on
the control head. It may take up to a minute for the 360 Imaging transducer and other
attached equipment to be detected by the control head.

1. Confirm Connections

1. Turn on the power source from the main switch.
2. On the control head, press the
on a control head in a multiple-control head Ethernet network, power on
the control head that is connected to the 360 Imaging transducer first.
3. When the Title screen is displayed, press the MENU key.
4. Select Normal. Press the RIGHT Cursor key.
5. Press and hold the VIEW key. Select System > Accessory Test. Confirm that
360 Imaging and GPS + Heading Sensor are listed as Connected. It will
take a minute for the equipment to be detected.
6. Press and hold the VIEW key. Select System > GPS Diagnostic View. Confirm
that External GPS is displayed and the Fix Type indicates Enhanced or 3D.
NOTE: If the GPS Diagnostic View or Accessory Test is not displayed in the
View Rotation, press the MENU key twice to open the Main Menu. Select the
Views tab > GPS Diagnostic View or Accessory Test. Change the setting for
each view to Visible.
