Humminbird Trolling Motor 360 Imaging Installation Manual page 26

WARNING! Do not install the pod too close to the propeller. If the pod is installed
too close to the propeller, it will be damaged.
AS 360 TM Ultrex
Adjusting the Pod Height
(at least 1" from the tip of the propeller)
1" (25.4 mm)
minimum shaft length
above bracket
1" (25.4 mm)
minimum
between pod
and propeller
