5. Add Offset Features to the 360 Imaging Display (optional)

The menu settings in this section are helpful for interpreting the position of objects
on the 360 View.
Adjust the 360 Heading Offset
If the positions of objects on the 360 Imaging display are slightly different than what
you observe in the environment around you, use 360 Heading Offset to correct the
alignment of the 360 Imaging display.
For example, if there is an object in the water that is displayed on the left side of the
360 View, but you can see that it is straight ahead, you can use this setting to rotate
the display.
NOTE: This menu option should be adjusted while the 360 Imaging transducer is
pinging.
1. Main Menu: Press the MENU key twice.
2. Select the Accessories tab > 360 Sonar Settings > 360 Heading Offset.
3. Press the RIGHT or LEFT Cursor keys to change the angle (gray line), and
press the CHECK/INFO key to confirm your setting. The zero point on the
display is represented by a green line.
Display the 360 Offset Icon
Use 360 Offset to display an icon representing the GPS Receiver/Heading Sensor
installation position on the 360 Imaging View. With the 360 Offset Icon displayed, it
is easier to interpret the position of objects on the view.
For example, if the GPS Receiver/Heading Sensor is installed 20 feet from the
360 Imaging transducer, set 360 Offset to 20. An icon will be displayed on the view
to show the Sensor (puck) position.
1. Measure the distance from the 360 Imaging transducer to the
GPS Receiver/Heading Sensor on your boat.
2. Main Menu: Press the MENU key twice.
3. Select the Accessories tab > 360 Sonar Settings > 360 Offset.
Control Head Setup 42
