STEP 3.

To replace, start at one corner and press firmly to
seat the gasket dart in the channel of the door/
drawer frame. Feel for a click to indicate the dart is
completely seated. Install all corners first and then
work your way around the perimeter of the door/
drawer to seat the gasket into its track.
STEP 4.
Finish by going around the gasket once more to
feel for any gaps and to ensure the gasket is flat
and fully seated.
Residential Drawer Mullion
Repair
STEP 1.
Remove drawer from the cabinet shell. One or
both drawers may need to be removed depend-
ing on accessibility for the service technician to
reach the screws holding the mullion in place.
Return to Table of Contents
NOTE: There are two screws on each end
behind the mullion.
STEP 2.
Shown in the picture below, it was the left side of
the mullion that was not flush with the unit's frame
and there's a high probability that the screw holes
on the mullion tab and the screw holes on the side
wall will not line up. Both screws were loosened
and with a hammer/rubber mallet, pound the mul-
lion out until it is flush with the frame and torque
down the screws. Avoid damaging the mullion
heater wire cover.
