Temp
Control
Models
Type
Digital
HC48RW,
HC48WW, 2nd
Compartment
Digital
HP48WO-S,
HP48WW-S,
1st
Compartment
Digital
HP48WW-S,
2nd
Compartment
NOTE:
Offset is the difference between the temperature that is actually being sensed and what is displayed to ensure
proper product temperatures.
Example: Set point 34, Offset +6, controller needs to sense 28F before the unit will turn off.
Delay: Control has a programmed time delay on temperature rise to show a stabilized temperature within the
refrigerated space.
Example: Set point 34F, unit cycles off, consumer opens the door, rather than have the temperature immedi-
ately shoot-up, it is delayed and will continue to show 34F until the delay time elapses. Meanwhile the
controller is sensing actual temperature and will turn on when it senses set point plus hysteresis.
Return to Table of Contents
Set Point Set Point Hysteresis
(F) Range (F) (Air Temp)
54 40-68 2
43 40-68 8
54 40-68 2
Electrical System Repair Instructions
Offset Delay Display
0 20 Air
Temp
10 20 Air
Temp
0 20 Air
Temp
Defrost Type Timing Post Defrost
N/A N/A
Programmed 12 Hrs
30 Mins
N/A N/A
Page 8-29
Fan Delay
N/A
N/A
N/A
