Table 8-11. HP15BO, BS, RO, RS, TO, TS, HK15BO, RO, TO Load Operation Modes

Models: HP15BO, BS, RO, RS, TO, TS, HK15BO, RO, TO
Electronic Control:
Defrost Style:
Cabinet Lighting:
Evaporator Fan:
LOAD
Compressor
Condenser Fan
Evaporator Fan

Table 8-12. HP15WO, WS, HK15WO Load Operation Modes

Models: HP15WO, WS, HK15WO
Electronic Control:
Defrost Style:
Cabinet Lighting:
Evaporator Fan:
LOAD
Compressor
Condenser Fan
Evaporator Fan
Return to Table of Contents
Dixell (XR60CX)
Programmed Defrost (12 hours--15 minutes)
Lights are controlled through a manual on/off switch as well as
through the door switch.
Is controlled by the door switch during Cooling Mode
COOLING MODE
Energized
Energized
Energized
Dixell (XR60CX)
Off Cycle Defrost
Lights are controlled through a manual on/off switch as well as
through the door switch.
Is controlled by the door switch during Cooling Mode
COOLING MODE
Energized
Energized
Energized
Electrical System Repair Instructions
OFF MODE DEFROST MODE
De-Energized De-Energized
De-Energized De-Energized
De-Energized Energized
OFF MODE DEFROST MODE
De-Energized N/A
De-Energized N/A
Energized N/A
Page 8-21
