Residential Refrigeration
and Front Venting Commercial Refrigeration
Service Manual
PROBLEM
Control not functioning
Lights not functioning
Light stays on when door is
closed.
Eliwell Control: LED
Controller display is flash-
ing "E1"
Return to Table of Contents
CAUSE
If Evaporator fan is still not running
No power to/from DC inverter/driver
(12V).
No power to unit.
Incorrectly wired harness.
No call for cooling.
Light switch in off position.
No power to light.
Faulty LED strip
Faulty/defective door switch or wiring to
door switch.
Door switch plunger bracket missing or
misaligned.
Manual switch is on.
Faulty/defective door switch or wiring to
door switch.
Door switch plunger bracket missing or
misaligned.
Probe 1 error. Reading out-of-range of
operating values.
Troubleshooting Guide – Beverage Dispensing
SOLUTION
Replace evaporator fan per Section 7.11 .
If no power: restore power, replace. Refer to
Section 1.1 .
Restore power to unit.
Refer to information plate. See Section 1.0
and Table 8-1
Verify wiring per wiring diagram, Section 8.2 .
Reconnect wires if needed.
Check probe connections and verify resistance
readings.
Check control settings.
Replace control.
Turn on light switch.
Verify wiring per wiring diagram, Section 8.2 .
Replace LED strip.
Check wiring for continuity of switch contacts.
Replace switch if faulty.
Install bracket and/or align properly.
Turn off manual switch.
Check wiring and continuity of switch contacts.
Replace switch if faulty.
Install bracket and/or align properly.
Check probe connections to control.
Check probe resistance readings per
Table 8-21 .
Check probe wiring.
Page 3-5
