Table 8-18. HC48RS, RW, WS, WW Load Operation Modes

Models: HC48RS, RW, WS, WW
Electronic Control:
Electronic Control:
Defrost Style:
Cabinet Lighting:
Evaporator Fan:
LOAD
Compressor
Condenser Fan
Evaporator Fan
Auxiliary Fan (RS, WS)
Second Compartment Fan
(RW, WW)
*Auxiliary Fan is used to circulate air through a single zone cabinet.
**Second Compartment Fan is for cooling and is controlled by second compartment controller.
Note: Lights and compartment fans are controlled individually by each door's switch.

Table 8-19. HP48WO-S, WW-S Load Operation Modes

Models: HP48WO-S, WW-S
Electronic Control:
Electronic Control:
Defrost Style:
Cabinet Lighting:
Evaporator Fan:
LOAD
Compressor
Condenser Fan
Evaporator Fan
Auxiliary Fan (RS, WS)
Second Compartment Fan
(RW, WW)
*Auxiliary Fan is used to circulate air through a single zone cabinet.
**Second Compartment Fan is for cooling and is controlled by second compartment controller.
Note: Lights and compartment fans are controlled individually by each door's switch.
Return to Table of Contents
Dixell (XR60CX) -- First Compartment (All models)
Dixell (XR20CX) -- Second Compartment (RW, WW models)
Programmed Defrost (12 hours-30 minutes)
Lights are controlled through a manual on/off switch as well as
through the door switch.
Is controlled by the door switch during Cooling Mode
COOLING MODE
Energized
Energized
Energized
Energized
Energized
Dixell (XR60CX) -- First Compartment (All models)
Dixell (XR20CX) -- Second Compartment (WW-S model)
Programmed Defrost (12 hours-30 minutes)
Lights are controlled through a manual on/off switch(es) as well as
through the door switch(es).
Is controlled by the door switch during Cooling Mode
COOLING MODE
Energized
Energized
Energized
Energized
Energized
Electrical System Repair Instructions
OFF MODE DEFROST MODE
De-Energized De-Energized
De-Energized De-Energized
De-Energized
Energized
De-Energized De-Energized
De-Energized N/A
OFF MODE DEFROST MODE
De-Energized De-Energized
De-Energized De-Energized
De-Energized Energized
De-Energized De-Energized
De-Energized N/A
Page 8-25
