Figure 7-18. Med Temp Refrigeration System Diagram - Perlick HA24BB Service Manual

Residential Refrigeration
and Front Venting Commercial Refrigeration
Service Manual
ITEM
NUMBER
1 Compressor
2 Condenser
3 Condenser Fan
4 Drier
5 N/A
Return to Table of Contents

Figure 7-18. Med Temp Refrigeration System Diagram

Refrigerator/Beverage Center/Wine Res/Beer Dispenser
DESCRIPTION
Refrigeration System Repair Instructions
ITEM
NUMBER
6 Capillary Tube
7 Heat Exchanger
8 Evaporator
9 Evaporator Fan
10 Temperature Control
DESCRIPTION
