Display Information
V-Chip Rating: Detects ratings from: MPAA (US), TV (US), Canadian
English, and Canadian French systems.
Transmission Signal Identifier (TSID): Indicates if the TSID is present in
the SDI stream. If missing, "Not Detected" will display; otherwise, the TSID
is displayed as a hexadecimal number.
Copy Generation Management System-Analog (CGMS-A): Indicates if
the CGMS-A is present in the signal. If missing, "Not Detected" will display;
otherwise, the CGMS-A value is displayed.
Broadcast Flag: Indicates if a broadcast flag was detected or not.
Timecode (TC) Flags: Indicates the timecode status. The drop frame (DF) is
0 when drop frame compensation is being performed normally. DF is 1 when
the count is not drop frame compensated. The color frame (CF) status is 0
when there is no relationship between the CF sequence and the time address.
CF is 1 when CF ID is applied to the time address.
Pol: Indicates the biphase polarity correction.
BG Flags: Indicates the binary group (BG) values and whether they are
specified. The readout will display a number from 0 to 7. For example, bit 0
is BGF0, bit 1 is BGF1, and bit 2 is BGF2.
BG Data: Indicates the binary group (BG) data value.
Wide Screen Signaling (WSS): Indicates if the WSS is present. The
supported formats include Composite PAL and 625-line SD. The WSS data is
displayed with the hexadecimal byte value and its description. WSS decoding
conforms to standard ITU-BT.1119-2.
Active Format Description (AFD): Indicates if the SMPTE 2016-1 and 3
Format for Active Format Description and Bar Data is present. The AFD
data is displayed with the hexadecimal byte value and its description. AFD
decoding conforms to standard SMPTE 2016 1-3.
Video Index Scanning B2-B0: Shows the Video Index Scanning System
information. Conforms to SMPTE RP186-2008 Class 1.1. Data Octet 1.
Scanning System provides information about the total number of lines, field
rate, and aspect ratio.
Video Index AFD/ARD B6-B3: Shows the Video Index binary value of Bits
6 to Bits 3 that are used to define the Active Format Descriptor. Conforms to
SMPTE RP186-2008 Class 1.1. or ARDSPEC 1. See the instrument online
help for a detailed description of codes: while the Aux Data Status display is
active in a tile, press the HELP button.
