WFM8200 and WFM8300 Waveform Monitors
Optional accessories. You may have ordered some of the optional accessories
that are available for your instrument. Some of these items will ship separately
from your main instrument. (See Table 3.)
If you have any questions about accessories that you ordered, contact your
Tektronix sales representative.

Table 3: Optional accessories

Accessory Description
WFM7F02
Portable cabinet with handle, feet, tilt bail, and front
panel cover.
WFMRACK-NN Dual rackmount for WFM8000 series, WFM6100
and series, WFM7000 series, WFM7100 series, 1700
WFMRACK-ON series, WFM601 series, WFM700 series, 760A, and
764. Option NN is used for WFM700, WFM6000
series, WFM6100 series, WFM7000 series,
WFM7100 series, and WFM8000 series monitors.
Option ON is used for 1700 series, WFM601 series,
760A, and 764 instruments. Both options include
an adapter to be used with the N sleeve that allows
housing of a WFM4000 series or WFM5000 series
instrument.
Analog audio
6 feet, male, 62-pin D connector to 8 XLR male output
breakout cable connectors and 12 XLR female input connectors.
WVR8RFP Remote front panel to remotely control the WFM8200
and WFM8300.
Requires user supplied hardware.
Service options. You can add any or all of the following service options to any
instrument. (See Table 4.)
Table 4: Service options
Option Description
Option CA1 Adds a single calibration or coverage for the first designated calibration
interval, whichever comes first.
Option C3 Adds 3 years of Calibration Service.
Option C5 Adds 5 years of Calibration Service.
Option D1 Adds a Calibration Data Report.
Option D3 Adds 3 years of Calibration Data Report (when ordered with option C3).
Option D5 Adds 5 years of Calibration Data Report (when ordered with option C5).
Option R3 Adds 3 years of Repair Service (including the period under warranty).
Option R5 Adds 5 years of Repair Service (including period under warranty).
Getting Started
Tektronix
part number
650-4393-XX
650-4445-XX
(WFMRACK-NN)
650-4394-XX
(WFMRACK-ON)
012-1688-00
WVR8RFP
5
