Audio Monitoring
156
Pro Logic Phantom. Pro Logic Phantom creates a Lt/Rt downmix of any input
with three or more channels. This Lt/Rt downmix will then use Pro Logic
decoding to produce a surround channel and provide LCS surround channels. This
surround channel is reduced 3 dB and reproduced in both the Ls and Rs bars.
A 2/0 encoded Dolby stream will be assumed to be Pro Logic encoded already and
will be Pro Logic decoded to produce a LRS output. Again, the surround channel
is reduced 3 dB and reproduced in both the Ls and Rs bars.
Any PCM input will be decoded to provide LCRS channels where the surround
channel is reduced 3 dB and reproduced in both the Ls and Rs bars.

Table 6: Channel modes versus Listening modes

Channel mode Listening mode
3/2 EX
Full
3 Stereo
Phantom
Stereo
Mono
PL Full
PL 3 Stereo
PL Phantom
2/2 EX
Full
3 Stereo
Phantom
Stereo
Mono
PL Full
PL 3 Stereo
PL Phantom
EX
3/1
Full
3 Stereo
Phantom
Stereo
Mono
PL Full
PL 3 Stereo
PL Phantom
Main channel output function
All 3/2 channels + EX decode of back surround
All 3/2 channels
3 Stereo downmix of 3/2 channels
Phantom downmix of 3/2 channels
Lo/Ro downmix
Lo+Ro
LCRS from Lt/Rt downmix
3 Stereo from Lt/Rt
Phantom from Lt/Rt
All 2/2 channels + EX decode of back surround
All 2/2 channels
Default to Stereo mode
Default to Full mode
Lo/Ro downmix
Lo+Ro
LCRS from Lt/Rt downmix
3 Stereo from Lt/Rt
Phantom from Lt/Rt
Default to Full mode
All 3/1 channels
S mixed into L and R with smix coefficient
C mixed into L and R with cmix coefficient
Lo/Ro downmix
Lo+Ro
LCRS from Lt/Rt downmix
3 Stereo from Lt/Rt
Phantom from Lt/Rt
