ARIB Displays
132
CC Data ID - Indicates the CC Data ID of the packet. Can be one of the
following:
Exchange Format CC
Exchange Format PMI
Exchange Format Page 1
Exchange Format Page 2
Short Form Management Data
Short Form Text
Undefined or Dummy Data
Set Mode - Mode can be either Sequential or Buffer.
Packet Flags - Indicates whether the packet is Leading, End, Intermediate,
or Single.
Checksum - Indicates the checksum word that was recovered from the
acquired packet.
Placement - Can display either OK or ERROR, indicating whether the ARIB
B.37 packets are present in the allowable configuration(s) specified in ARIB
TR-B.23.
WFM8200 and WFM8300 Waveform Monitors
