WFM8200 and WFM8300 Waveform Monitors
Table 1: Key features (cont.)
Item Description
Audio monitoring Surround Sound display of audio signals and phase relationships
of normal channel pairs.
Lissajous display lets you monitor a user-specified pairing of
channel inputs.
Support and options for viewing and monitoring both levels of
normal channel pairs for AES, analog, embedded audio, and Dolby
signals.
Loudness measurement, audio control packet coding, and many
popular audio scales, including BBC scales, are also supported.
Displays selected Dolby Metadata parameters present in the Dolby
D, Dolby Digital Plus, and Dolby E bitstream.
Displays Dolby E Guardband measurements.
Auxiliary data Support for monitoring auxiliary data including data conforming to
monitoring ARIB standards and CEA608, CEA708, AFD, and CGMS-A.
Audio Video Delay Measures the duration that the video system advances or delays
the audio signal relative to its correct temporal position.
Timing display
A Tektronix proprietary display that simplifies measuring the timing
difference between two signals. Using the Timing display enables
you to easily compare and correct the timing between two signals.
Closed Captioning Support for simultaneous decode and display in multiple languages
support of CC standards (CEA 608 (VBI), CEA 608 (ANC), CEA (608/708),
CEA 708, TeletextB (VBI), TeletextB OP47 SDP (ANC), and
TeletextB OP47 Multi (ANC)) with caption text and V-chip
information overlaid on the picture (monitor mode). There are also
settings for missing or incorrectly inserted closed captioning.
Picture area Support for standard and custom Safe Graticules for Picture
displays that look for incorrect placements of graphics, logos, Black
events, and Frozen events. Two Safe Area graticules and Safe
Title graticules are supported.
Status screens Status screens provide content status at a glance.
Physical Verification and automatic measurement of the electrical
measurements characteristics of the SDI physical layer. An Eye display lets you use
(Requires Option the graticule or voltage and time cursors to measure the waveform.
EYE or PHY) A Jitter waveform display shows jitter and jitter thermometers
provide two independent measurements of jitter and one of cable
loss, and relates those measurements to defined alarm limits.
Waveforms can also be set, tile by tile, to Infinite Persistence. This
mode traces waveforms over time on the same display, providing a
visual history of the trace.
Error tracking Configurable alarms and error logging.
Remote control Full remote control for complete installation flexibility.
Data List display Examines the contents of all digital formats, structures, and
transports and displays the data without any interpolation.
