High-Pass Filter
WFM8200 and WFM8300 Waveform Monitors
The high-pass filter bandwidth setting allows you to show only jitter terms above
the selected filter frequency. When you select a filter setting, depending on the
active input signal, you select the jitter measurement type (Timing, Alignment, or
neither, as defined by the SMPTE standard).
To choose the Jitter high-pass filter, use the Measurement pop-up menu and
choose one of the following settings for the Jitter HP Filter entry:
Setting Description
Timing Sets the detector high-pass filter to 10 Hz. This is the correct value for
measuring timing jitter for both SD and HD signals.
Align Sets the detector high-pass filter to 1 kHz, as specified by SMTPE, for SD
signals; and to 100 kHz for HD signals. These are the correct values for
measuring alignment jitter.
10 Hz, 100 Hz, Sets the detector high-pass filter to the selected value.
1 kHz, 10 kHz,
100 kHz
NOTE.
For instructions on how to take jitter measurements, see Monitoring the
SDI Physical Layer. (See page 101.)
