WFM8200 and WFM8300 Waveform Monitors
Table 5: Instrument options (cont.)
Option
Audio AD
DPE
62
Measurement EYE
and Analysis
PHY
PROD
DAT
Instrument
model Description
WFM8200, Adds Analog Audio Monitoring (2 sets
WFM8300 of 6 channel Analog Audio inputs and
8 channels of Analog Audio outputs);
16 channels Embedded and AES/EBU
Digital Audio support (8 channels at
a time).
WFM8200,
Adds Option AD capabilities (Analog
WFM8300
and Digital Audio, Embedded or
External AES), plus support for
decoding and monitoring Dolby E,
Dolby D, and Dolby Digital Plus Audio
(Audio cable available separately).
(See Table 3.)
WFM8200, Analog Audio Breakout Cable, 6 feet,
WFM8300 male 62-pin connector to 8 XLR male
output connectors and 12 XLR female
input connectors.
WFM8200 Adds Eye Pattern Display and Jitter
Measurement Package (includes
3G-SDI, HD-SDI, and SD-SDI
Eye pattern display; automated
measurements of jitter and cable
parameters); Option 3G required for
3G-SDI support.
WFM8300 Adds Physical Layer Measurement
Package (includes 3G-SDI, HD-SDI,
and SD-SDI Eye pattern and jitter
waveform displays; automated
measurements of Eye pattern
parameters, jitter, and cable
parameters; color bar and pathological
signal generation); Option 3G required
for 3G-SDI support.
WFM8200, Adds Advanced Gamut Monitoring
WFM8300 Package (Spearhead Display and
Luma Qualified Vector Display)
WFM8200 Adds data analysis capabilities.
Allows for logic-level view of video
and embedded audio data stream and
ANC data extraction.
