Getting Started

Incoming Inspection

Basic Turn On and Self
10
SNMP Trap Address
Private Community String
Public Community String
The incoming inspection procedures are optional procedures to check the
functionality of your instrument. These procedures require no equipment
other than an external monitor or display. For a more robust inspection, see
the performance verification procedures in the WFM8200 and WFM8300
Specifications and Performance Verification Technical Reference that is included
on the Product Documentation CD that shipped with your instrument.
You can perform the following test with or without the external monitor. Using
the external monitor allows you to check that the DVI connector on the rear panel
Test
is working properly:
1. Connect a monitor to the EXT DISPLAY connector on the rear panel of the
instrument. This connector is a DVI-I connector with socket contacts. The
output supports DVI monitors directly and analog PC (RGB) monitors using a
DVI-I to VGA adapter.
2. Connect the AC line cord to the rear of the instrument and to a 100 to
240 VAC source.
This menu entry allows you to set IP addresses to which SNMP
traps are sent through SNMP. Traps can be sent to up to four
addresses when error conditions are detected.
NOTE.
A value of all zeroes for the address will disable that
trap output.
This menu entry allows you to set the Private Community string.
This string is effectively a password. Without this string, SNMP
commands cannot change values in the instrument.
NOTE.
The Private String is necessary for SNMP access to
write changes into the instrument.
This menu entry allows you to set the Public Community string.
This string is effectively a password. Without this string, SNMP
commands cannot read values from the instrument.
NOTE.
The Public String is necessary for SNMP access to
read values from the instrument.
WFM8200 and WFM8300 Waveform Monitors
