Presets

WFM8200 and WFM8300 Waveform Monitors
The headphone jack is located on the front panel of your instrument. You can
adjust the volume to the headphones from the Audio menu as follows:
1. Press the AUDIO button to show the audio display in a tile.
NOTE.
The headphone icon appears at the bottom of the Audio display.
2. Use the Horizontal knob to adjust the volume.
3. Adjust the headphone source by pressing the AUDIO button, selecting
Headphone Input, and then selecting the source you want.
Instrument setups can become complex as you tailor them to monitor various
parameters. To save set up time and ensure consistency, you can save instrument
setups as presets in your instrument. Save and quickly access presets from the
PRESET button on the instrument front panel and from the instrument Web page.
All instrument settings except those set in the Utilities and Network Settings
submenus of the Configuration menu are saved in a Preset. Settings that are not
saved are those such as the clock setting, IP configuration, and network address.
The following is an overview of the settings saved in a Preset:
Measurement assigned to each tile
Tile specific settings
Input selection
SDI Input settings
Composite Input settings
External Reference settings
Audio Displays settings
Audio Inputs/Outputs settings
Alarm settings
Gamut thresholds
Display settings
Readout setting
Graticule settings
Functions
93
