PARALLEL CONFIGURATION
PARALLEL 1+1 REDUNDANT CONFIGURATION CONNECTIONS.
3/3
Output transformer (standard confi guration).
WARNING!
Before connecting TA4 and TA5 remove the bridge cable from TA4-TA5 on both UPSs
TA1 TA2 TA4 TA5
L1 L2 L3
MAINS
SUPPLY
MAINS
cable section: ø 1.5 - 2.5 mm
TA1 TA2 TA4 TA5
L1 L2 L3
MAINS
SUPPLY
MAINS
60
IOMMASIPXX09-GB 04
N L11 L21 L31 N1 L14 L24 L34
AUXILIARY OUT
MAINS TRANSFORMER
AUXILIARY TO
MAINS LOAD
2
N L11 L21 L31 N1 L14 L24 L34
AUXILIARY OUTPUT
MAINS
AUXILIARY
MAINS
MASTERYS IP+
N4 L13 L23 L33 N3 L12 L22
IN
OUTPUT
TRANSFORMER
Cables provided
N4 +B2 -B2 -B1 +B1
EXT. BATTERY
10-40 kVA
L32 N2 +B2 -B2 -B1 +B1
EXT. BATTERY
Cables Cables
LEFT UPS
provided provided
RIGHT UPS
