COMMUNICATION

9.3 ACCESSORIES AND SW OPTIONS.

A large number of SW solutions can be adopted on MASTERYS
These solutions have been specially designed for the effi cient management of power protection devices.
UNI VISION PRO is the solution for managing a UPS connected to the local server via RS232 interface or via LAN
network. It is normally used at departmental level to automatically shutdown the systems and ensure secure control
of the UPS that in turn protect servers and workstations. The main functions are:
• Graphic monitoring of the UPS via web browser
• Local shutdown of a server connected via serial interface
• Remote shutdown via proxy agent and optional Java shutdown clients
• Notifi cation of anomalies via e-mail to a maximum of 8 addresse.
NET VISION is a solution for managing UPS units connected directly to the local network. It is normally used on
medium/large, complex networks and in multi-server environments where the IT manager centrally controls all the
network resources. The physical position of the UPS is not signifi cant. The main functions are:
• 10/100Mb Ethernet connection (RJ45)
• Graphic monitoring of the UPS via web browser
• Remote shutdown of up to 40 computers
• Notifi cation of anomalies via e-mail to a maximum of 8 addresses
• UPS management using SNMP protocol
• Diagnostics via Internet off ered by e-Service.
Java & .NET shutdown Client (JNC) is an optional Java application to be installed on a server for the automatic
shutdown of the computers on the network before the UPS stops due critical operating conditions (imminent battery
failure, overload, etc.). It is supplied as an option and can be associated to the UNI VISION PRO or NET VISION commu-
nication solutions. The main features/functions are:
• Use of the TCP/IP standard network protocol
• Graphics interface for easy confi guration
• Minimum use of CPU resources
• Personalisation of shutdown parameters and script
• Continuous monitoring of the effi ciency of the connection to the UPS.
T.Service is a cutting edge supervision service ensuring 24/7/365 service. It ensures eff ective prevention and con-
stant monitoring of the system. Communication between the UPS and the local Socomec Service Centre is via
modem (free-air GSM or ANALOG fi xed line). The auto-diagnostic system analyses UPS operating conditions, identi-
fi es faults and monitors environmental conditions such as temperature, overload, avoiding the risk of equipment
stoppages. In the event of a failure, the system immediately sends a "diagnostic report" via modem to the Service
Centre. Any emergency situation is managed and resolved extremely quickly and remotely by the Service Centre,
with immediate intervention on site if needed.
46
IOMMASIPXX09-GB 04
MASTERYS IP+
TM
thanks to its advanced communication facilities.
10-40 kVA
