socomec MASTERYS IP Plus Installation And Operating Manual page 15

UNPACKING AND INSTALLATION
3
OF THE UNIT
MAINS AND AUXILIARY MAINS ARE CONNECTED SEPARETELY.
3/3
Output transformer (standard confi guration)
L1 L2 L3
TA1
MAINS
SUPPLY
TA2
Cable Cable
provided provided
MAINS
cable section
ø 6÷35 mm
MAINS AND AUXILIARY MAINS ARE CONNECTED IN COMMON.
3/3
Output transformer
L1 L2 L3
TA1
TA2
Cable Cable
MAINS
SUPPLY
provided provided
MAINS
cable section
ø 6÷35 mm
N L11 L21 L31 N1 L14 L24
AUXILIARY OUT
MAINS TRANSFORMER
AUXILIARY TO
MAINS LOAD
2
cable section cable section
2
ø 6÷35 mm ø 6÷35 mm
N L11 L21 L31 N1 L14 L24
OUT
TRANSFORMER
AUXILIARY
MAINS
TO LOAD
cable section
2 ø 6÷35 mm
MASTERYS IP+
L34 N4 L13 L23 L33 N3 L12
IN
TRANSFORMER
2
L34 N4 L13 L23 L33 N3 L12
IN
TRANSFORMER
2
10-40 kVA
L22 L32 N2 +B2 -B2 -B1 +B1
OUTPUT EXT. BATTERY
Cables Cables
provided provided
L22 L32 N2 +B2 -B2 -B1 +B1
OUTPUT EXT. BATTERY
Cables Cables
provided provided
IOMMASIPXX09-GB 04
15
