UNPACKING AND INSTALLATION
3
OF THE UNIT
MAINS AND AUXILIARY MAINS
3/3
ARE CONNECTED SEPARATELY.
Transformer on the rectifi er
power supply input
L1 L2 L3
TA2
TA3
Cable Cable
MAINS
SUPPLY
provided provided
Cables Cables
provided provided
MAINS AND AUXILIARY MAINS
3/3
ARE CONNECTED SEPARATELY.
Transformer on the bypass
power supply input
L1 L2 L3
TA2
MAINS
TA3 SUPPLY
Cable Cable
provided provided
MAINS
cable section
ø 6÷35 mm
16
IOMMASIPXX09-GB 04
N L11 L21 L31 N1 L14 L24
AUXILIARY OUT
MAINS TRANSFORMER
AUXILIARY MAINS
cable section
2
ø 6÷35 mm
N L11 L21 L31 N1 L14 L24
AUXILIARY OUT
MAINS TRANSFORMER
2 Cables Cables
provided provided
MASTERYS IP+
WARNING!
Remove the connecting cables provided between
OUTPUT and IN TRANSFORMER and use them to
connect MAINS SUPPLY and OUT TRANSFORMER.
Move the bridge cable provided from TA1-TA2 to
TA2-TA3.
L34 N4 L13 L23 L33 N3 L12
IN
TRANSFORMER
MAINS TO LOAD
cable section cable section
2
ø 6÷35 mm ø 6÷35 mm
WARNING!
Remove the connecting cables provided between
OUTPUT and IN TRANSFORMER and use them to con-
nect AUXILIARY MAINS and OUT TRANSFORMER.
Move the bridge cable provided from TA1-TA2 to
TA2-TA3.
L34 N4 L13 L23 L33 N3 L12
IN
TRANSFORMER
AUXILIARY TO LOAD
MAINS
cable section
ø 6÷35 mm
cable section
ø 6÷35 mm 2
10-40 kVA
L22 L32 N2 +B2 -B2 -B1 +B1
OUTPUT EXT. BATTERY
2
L22 L32 N2 +B2 -B2 -B1 +B1
OUTPUT EXT. BATTERY
2
