3.5 ELECTRICAL REQUIREMENTS.
The installation and the system must comply with national plant regulations.
The electrical distribution panel must have a protection and sectioning system installed for the input mains and the
auxiliary mains. If a diff erential switch is installed on the mains power switch (optional), it must be inserted upstream
from the distribution panel.
The table below show the size of the input protection devices recommended for correct installation.
WARNING!
The default transformer is normally connected to the output.
Size of the input protection devices
UPS
Magneto-thermal
input
1
[kVA]
[A]
single
parallel
2
32
40
100
125
10 3/1
if common
if common
input mains
input mains
32
40
15 3/1
100
125
if common
if common
input mains
input mains
40
63
125
160
20 3/1
if common
if common
input mains
input mains
63
80
160
200
30 3/1
if common
if common
input mains
input mains
10 3/3
32
40
15 3/3
32
40
20 3/3
40
63
30 3/3
63
80
40 3/3
80
100
1
Recommended magneto thermal switch: four poles with intervention threshold ≥ 10 In
2
In systems with two or more UPSs operating in a redundant or power parallel confi guration.
3
Determined by the size of the terminals.
4
Protection on the external battery cabinet.
5
Caution! Use type B four-pole selective (S) circuit breakers. Load leakage currents are added to those generated by the UPS and during transitory
phases (power failure and power return) short current peaks may occur. If loads with high leakage current are present, adjust the diff erential
protection. It is advisable in all cases to carry out a preliminary check on the earth current leakage with the UPS installed and operational with the
defi nitive load, so as to prevent the sudden activation of the above switches.
12
IOMMASIPXX09-GB 04
Magneto-thermal
Diff erential
Auxiliary Mains
1
input
5
[A]
[A]
single
parallel
2
selective type
100
125
0.5
100
125
0.5
125
160
0.5
160
200
0.5
32
40
0.5
32
40
0.5
40
63
0.5
63
80
0.5
80
100
0.5
MASTERYS IP+
Input cable
Output/Aux
core size
cable core size
2
2
[mm
]
[mm
]
5
min-max
3
min-max
3
6÷35
16÷50
6÷35
25÷50
10÷35
35÷50
16÷35
50
6÷35
6÷35
6÷35
6÷35
10÷35
10÷35
16÷35
16÷35
25÷35
25÷35
10-40 kVA
Battery cable
Battery
core size
protection
4
2
[mm
]
[A]
6÷35
50 Gr
6÷35
50 Gr
10÷35
50 Gr
16÷35
100 Gr
6÷35
50 Gr
6÷35
50 Gr
10÷35
50 Gr
16÷35
100 Gr
25÷35
100 Gr
