IP52 VERSION
TECHNICAL SPECIFICATIONS
Models
Input/Output phases
Electrical specifi cations - Input
Mains voltage
Input frequency
Input power factor
THDI
Electrical specifi cations - Output
Output voltage (three phase + neutral)
Frequency
Automatic bypass
Nominal power (kW)
Overload on automatic bypass @ 25 °C
Crest factor
Voltage distortion
(1) @ Pout = 90% Pnom.
(2) With transformer on output or bypass
Environment
Operating temperature
Storage temperature
Relative humidity
Max. altitude
Acoustic noise (dB)
3
Required cooling capacity (m /h)
Dissipated power max (W)
Dissipated power (BTU/h)
Standards
Safety
Type and performance
EMC
Product certifi cation
Protection level
10 15
3/1 and 3/3 3/1 and 3/3
10 15
3P+N 400 V +20% -15% (up to -35% @70% of nominal load)
50-60 Hz ±10%
< 2.5%
10 15
230 V single phase (selectable: 208
400 V three phase (selectable 360
50-60 Hz ±2% (from 1% to 8% if generator is used)
nominal output voltage ±15%
(from 10% to 20% selectable if generator is used)
8 12
(2) 20 minutes @ 125%, 4 minutes @ 150%, 2 minutes @ 200%
1% with linear load
10 15
0÷35 °C
-5÷45 °C
0÷95% condensation-free
1.000 m (3.300 ft) without derating; 3.000 m (10.000 ft) max
< 52 < 52
625 625
680 900
2300 3050
10 15
EN 62040-1-1, EN 60950-1
EN 62040-3 (VFI-SS-111)
EN 62040-2
MASTERYS IP+
20 30
3/1 and 3/3 3/1 and 3/3
20 30
0,99
20 30
(1)
/220/230/240 V) ±1%
(1)
/380/400/415 V) ±1%
16 24
3:1
20 30
< 52 < 55
625 625
1150 1750
4070 6050
20 30
CE
IP52
10-40 kVA
800
600
Weight: up to 500 kg
