Summary of Contents for socomec MASTERYS EM

  • Page 1 YOUR CONNECTION TO SAFETY CPSS Emergency MASTERYS EM 1 0 t o 8 0 k V A Manual de instalación y uso Manuel d’installation et d’utilisation Installation and operating manual Manuale di installazione e uso Manual de instalação e funcionamento...
  • Page 2 UPS inactivity. SOCOMEC may, at its own discretion, opt for the repair of the product or the replacement of faulty or defective parts with new parts, or with used parts of equivalent quality to new parts with regard to function and performance.
  • Page 3: Table Of Contents

    13. TECHNICAL SPECIFICATIONS ..........41 CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00...
  • Page 4: Safety Standards

    (UPS). • SOCOMEC retains the full and exclusive ownership rights over this document. Only a personal right to use the document for the application indicated by SOCOMEC is granted to the recipient of this document. The reproduction, modification, distribution of this document either partially or wholly, and in any way, is strictly prohibited except upon Socomec’s express prior written consent.
  • Page 5: Description Of Symbols

    For such use please contact SOCOMEC beforehand to check if these products meet the required level of safety, performance, reliability and comply with applicable laws, regulations and specifications.
  • Page 6: Enviromental Requirements And Moving

    CAUTION IF DAMAGED. If the unit is found to be damaged externally or internally, or any of the accessories are damaged or missing, contact SOCOMEC. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to...
  • Page 7: Electrical Installation

    The PE cable core size must be chosen according to the PROTECTIVE CURRENT RATING of the earth circuit which depends on the provision and location of protective overcurrent devices. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to...
  • Page 8 For equipment with separate Emergency Mains, it must be possible to make the neutral of the Emergency Mains line electrically common with the neutral of the main input feed line. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to...
  • Page 9: Overview

    Switch in position 1 Q6 switch Switch in position 0 (OFF) Switch in position 1 (UPS) Switch in position 2 (BYPASS) CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to...
  • Page 10 Serial connector RS232/485 USB connector Options slot 2 Ethernet network Serial connector RS232 MAINS MAINS CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to klick to u-s-v Y O U R C O N N E C T I O N TO S A F E T Y...
  • Page 11 (2) Connects the UPS output to the inverter (continuous power supply). (3) Connects the output directly to the auxiliary mains input (manual bypass). CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to...
  • Page 12: Connections

    If there is no separate mains for the bypass it is advisable to obtain one from the primary mains using either of the two methods set out below. 5.1-2 With distribution external to the UPS Mains Mains Mains CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to klick to...
  • Page 13 - leave a space of at least 20 cm between the power and the control cables; - avoid parallel channelling over long distances; choose cables crossing at 90° instead. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to...
  • Page 14 YOUR CONNECTION TO SAFETY ASSEMBLY 5.1-5 UPS 10 TO 40 kVA 5.1-6 UPS 60 TO 80 kVA CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to klick to u-s-v...
  • Page 15: External Battery Connection

    A remote emergency shutdown system (ESD) can be installed by means of the optional ADC PCB; (see chapter 'STANDARD FEATURES AND OPTIONS'). Connect a normally closed zero-potential contact to terminals IN1+ and IN1- of the ADC PCB. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to...
  • Page 16: Control Panel

    UPS in maintenance mode GREEN fl ashing Battery test GREEN Load powered from inverter or in high effi ciency mode CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to...
  • Page 17 Flashing Activation code alarm Flashing General alarm Steady LAN connection ready (Cable Connected) Steady CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to klick to u-s-v Y O U R C O N N E C T I O N TO S A F E T Y...
  • Page 18: Menu

    PRESENT DATA SERVICE COMMISSIONING SETTING SERVICE CODE HISTORY HISTORY LOG CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to klick to u-s-v Y O U R C O N N E C T I O N TO S A F E T Y...
  • Page 19: Menu Function Description

    The battery switch is open A60 FAN FAILURE Fans faulty or blocked. A61 PHASE ROTATION FAULT Wrong phase cycle direction. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to...
  • Page 20 ENTER displays weekly ENTER displays 24 hr graphics graphics WORKING TIME ON GEN SET NUMBER OF HOURS CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to klick to u-s-v...
  • Page 21 UP RV 000 CKS: 0000 Identifi es the Mac address of LAN PCB. DSP RV 000 CKS: 0000 CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to klick to...
  • Page 22 ENTER to move to the next letter. Note: column A shows whether or not the parameter is visible in the PARAMETER CONFIGURATIONS menu. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to...
  • Page 23 Sets the LCD display contrast 0/100 • STATISTICS PERIOD Indicates the time in weeks for the calculation of statistics 1-10 CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to...
  • Page 24 It is possible to lock/unlock the keyboard using the buttons in the following sequence: ENTER, DOWN , UP , ESC (held for over 3 seconds). The sequence must be completed in no more than 15 seconds. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to...
  • Page 25: Operating Procedures

    If there is an external manual bypass, put the switch to position OFF. • From the mimic panel set the NORMAL MODE command from the IMMEDIATE COMMANDS menu. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to...
  • Page 26: Ups 60 To 80 Kva

    • Set switch Q3 to position 0 (inverter in output OFF). • Set the battery switches to position 0 (battery circuit open). • Set switch Q4 to position 0 (input mains OFF). CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to...
  • Page 27 If the UPS is operating from the manual bypass (Q5 in position 1) with mains present, the emergency shutdown does not interrupt the power supply to the load. In emergency conditions all the power supplies upstream of the UPS must be disconnected. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to...
  • Page 28: Operating Modes

    Eco Mode operation provides very high efficiency, since the application is powered directly from the auxiliary mains via the automatic bypass under normal operating conditions. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to...
  • Page 29: Mode Without Cut Off (Converter Mode)

    This operating mode can be selected for maintenance to be carried out on the system so that the necessary actions can be per- formed by service personnel without having to disconnect the power supply to the load. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to...
  • Page 30: Standard Features And Options

    6 Not connected 7 Reserved 7 RTS 8 CTS 8 Not connected 9 +12 V 9 +12 V CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to klick to u-s-v...
  • Page 31: Standard Webpages

    Using the UPS MONITOR link on the menu it is possible to return to the UPS synoptic. In the case of a parallel system a line is added at the bottom of the display showing the current status of each unit. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to...
  • Page 32 All active events are listed in the e-mail body. If the event has been cancelled by the UPS a cancelled event e-mail is also sent. It is possible to send a test e-mail. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to...
  • Page 33: Adc Card

    (1) If the external ESD button is not used always insert a jumper to short circuit input IN 1. (2) On ADC with temperature sensor is used as input dedicated to the external battery temperature probe CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to...
  • Page 34: Adc Card With Temperature Sensor

    - Mains failure >10 seconds and load rate > 85%. - Mains failure >30 seconds and 'battery low' condition - In the presence of mains with overload > 15 seconds CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to...
  • Page 35: Insulation Controller

    Refer to the following paragraphs for details on electrical connections and on activating the chosen protection. OUTPUT MAINS SUPPLY AUX MAINS SUPPLY EXTERNAL BATTERY CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to klick to...
  • Page 36: Protection On Mains Supply And On Auxiliary Mains Supply

    125 A AC1 Connector on BKF PCB Connector on BKF PCB 80 3/3 140 A AC1 140 A AC1 CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to klick to...
  • Page 37: Protection On An Ups Without Auxilary Mains Supply

    L1-L2-L3-N Input power source Input power terminal board Input power switch Remote switch Connector on BKF PCB CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to klick to u-s-v...
  • Page 38: Warning And Troubleshooting

    PHASE ROT. FAULT The phase cycle sequence is incorrect. rate auxiliary mains exchange the two phases of the auxiliary mains only. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to...
  • Page 39 FAN FAILURE Fault in the ventilation system at the back of the UPS are not obstructed. CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to...
  • Page 40: Maintenance

    These parts must be replaced. • Make sure that cables and screws are well secured. • Make sure that equipment is clean. Contact SOCOMEC service centre to request machine cleaning. 12.1. PREVENTIVE MAINTENANCE The equipment should be inspected at annual intervals to ensure continued trouble-free operation.
  • Page 41: Technical Specifications

    EN 62040-1-1, EN 60950-1 Type and performance EN 62040-3 (VFI-SS-111) EN 50171 EN 62040-2 Product certification Protection level IP20 CPSS Emergency MASTERYS EM 10 to 80 kVA - Ref.: IOMMASELXX03-GB 00 klick to klick to klick to klick to klick to u-s-v...
