Once the code is obtained, enter it by pressing ENTER to activate the entry (two asterisks will appear). Select the
fi rst character with the UP
on to the next character. Pressing the ENTER key after selecting the fourth character activates code.
An error message is displayed if the code is incorrect.
Check that the code displayed corresponds to the one provided by the Support Centre and repeat the procedure.
8.5.2 "Present confi gurations" menu.
This is used to change the confi guration parameters.
Press ENTER. Access is via the password MAST which is keyed in by using the UP
ENTER to go on to the next letter.
Note.
Column A shows whether the parameter is visible in the PARAMETERS "CONFIGURATIONS" menu.
PRESENT CONFIGURATIONS menu
A Parameter
LANGUAGE SELECTION
• NUMBER OF MODULES
• REDUNDANCY LEVEL
• OUTPUT VOLTAGE
• OUTPUT FREQUENCY
• CONVERTER
• AUTO ON
BATTERY AVAILABLE
BATTERY TEMP. PROBE
• BATTERY TYPE
• BATTERY RECHARGE
• BATTERY CAPACITY
• BATTERY ELEMENTS
and DOWN keys and confi rm with ENTER to accept the character. Then move
SEE INSTALLATION MANUAL
FOR PROCEDURE
CODE = - - - - **
Description
Selects the required language
Only appears in case of parallel systems.
Indicates the number of UPSs in the system.
Only appears in case of parallel systems.
Indicates the number of redundant UPSs.
Sets the required output voltage value.
Sets the required output frequency value.
Sets whether the UPS has to operate as a frequency
converter.
WARNING!
Set only on UPS with mains power (MAINS) and auxiliary mains (AUX MAINS) separated
and with the auxiliary mains (AUX MAINS) disconnected!
Do not set on UPS with common mains lines as it could damage the load!
Sets whether the UPS has to restart automatically after
shutdown due to minimum battery level.
Indicates whether the batteries are present
Indicates if the battery sensor is present
Selects the type of batteries used
Selects the type of recharge required
Sets the battery capacity in Ah.
Indicates the number of elements in series
in a branch.
MASTERYS IP+
and DOWN
Allowed values
DE-EN-ES-FR-IT, others on request
1-6
FROM 0 TO THE NUMBER
OF MODULES LESS ONE
208/220/230/240
50/60
YES/NO
YES/NO
YES/NO
ENABLE/DISABLE
SEALED, OPEN VENT, NI-CD
AUTO, MAINTENANCE,
2 LEVELS, INTERMITTENT
6,50 ÷ 1.000 (x number of UPS)
114÷132
