UNPACKING AND INSTALLATION
3
OF THE UNIT
UPS IN NEUTRAL VERSION WITHOUT NEUTRAL ON THE NETWORK
3/3
output transformer
L1 L2 L3
TA1
MAINS
TA2 SUPPLY
Cables Cables
provided provided
MAINS
cable section
ø 6÷35 mm
Do not combine the main network and the auxiliary network
MAINS AND AUXILIARY MAINS ARE CONNECTED SEPARETELY.
3/1
Output transformer
L11 L21 L31 N1 L14 L24
AUXILIARY OUT
MAINS TRANSFORMER
AUXILIARY TO LOAD
MAINS
cable section
2 ø 6÷35 mm
cable section
ø 6÷35 mm 2
L1 L2 L3 N L11A
MAINS
SUPPLY
MAINS
cable section
ø 6÷35 mm 2
MASTERYS IP+
L34 N4 L13 L23 L33 N3 L12
IN
OUTPUT
TRANSFORMER
2
L11 N11A N11 L14 N4 L13
AUXILIARY OUT
MAINS TRANSFORMER
IN
TRANSFORMER
AUXILIARY TO
MAINS LOAD
cable section
2
ø 16÷50 mm
10-40 kVA
L22 L32 N2 +B2 -B2 -B1 +B1
EXT. BATTERY
Cables Cables
provided provided
N3 L12 N2 +B2 -B2 -B1 +B1
EXT. BATTERY
OUTPUT
Cables Cables
provided provided
