MENU

8.1 "ALLARMS" MENU
This is used to display all the alarms that are active at the time of access.
The alarms menu is activated automatically when an alarm condition occurs.
ALARMS menu
Code Mimic panel description
A00 GENERAL ALARM
A01 BATTERY ALARM
A02 OUTPUT OVERLOAD
A06 AUXILIARY MAINS OUT OF TOLERANCE
A07 OVER TEMPERATURE
A08 MAINTENANCE BYPASS ACTIVE
A17 IMPROPER CONDITION OF USE
A18 BLOCKING INVERTER FOR OVERLOAD
A20 WRONG CONFIGURATION
A22 INPUT MAINS OUT OF TOLERANCE
A23 RECTIFIER GENERAL ALARM
A25 INVERTER GENERAL ALARM
A26 BATTERY CHARGER GENERAL ALARM
A29 BYPASS GENERAL ALARM
A30 STOP FOR OVERLOAD
A32 MODULE 1 GENERAL ALARM
A33 MODULE 2 GENERAL ALARM
A38 EXTERNAL ALARM 1
A39 EXTERNAL ALARM 2
A40 EXTERNAL ALARM 3
A41 EXTERNAL ALARM 4
A42 E-SERVICE GENERAL ALARM
A43 REDUNDANCY LOST
redundancy N+x to be maintained (for UPSs in parallel only).
A44 PERIODIC SERVICE CHECK-UP
A47 MAX BATTERY TEMPERATURE
A49 BATTERY DISCHARGED
A51 OPTION BOARD GENERAL ALARM
A56 GENERATOR SET GENERAL ALARM
A57 GENERATOR SET FAULT
A58 E.S.D. ACTIVATED
A59 BATTERY CIRCUIT OPEN
A60 FAN FAILURE
A61 PHASE ROTATION FAULT
Meaning
Battery circuit failure or faulty operation.
Power required in output over the limits.
The voltage or frequency limits accepted by the bypass have been
exceeded.
Temperature excessive or ventilation problems.
Q5 in position 1.
Improper conditions of use verifi ed (load, mains, and temperature).
Inverter shutdown due to overload.
Error in the confi guration parameters (e.g. diff erent parameters
between several UPSs in parallel).
The voltage or frequency limits accepted by the rectifi er have been
exceeded.
Rectifi er fault.
Inverter fault.
Battery charger fault.
Bypass fault.
The duration of the overload has inhibited the bypass.
Module 1 failure.
Module 2 failure.
Signalling from ADC input.
Signalling from ADC input.
Signalling from ADC input.
Signalling from ADC input.
Alarm that generates automatic sending of a signal to the support
centre (if the service has been activated).
The power required by the load no longer allows the preset
Warning for periodic check by support service.
Control of the temperature of battery cabinet.
The energy available in the battery has been used up.
Fault related to the optional PCBs in the slots.
Minor alarm on generator set.
Major alarm on generator set.
The remote emergency shutdown command has been activated.
The battery switch is open.
Fans faulty or blocked.
Wrong phase cycle direction.
